Micro:bit Driver Expansion Board
|
Gravity: Dual Bipolar Stepper Motor Shield for Arduino (DRV8825)
|
Quad DC Motor Driver Shield for Arduino
|
| SKU |
DRI0001
|
DFR0548
|
DRI0023
|
DRI0039
|
Chip
|
L293B
|
HR8833
|
DRV8825
|
TB6612FNG
|
Operating voltage
|
5V DC |
/ |
3.3V/5V |
2.7~5.5V
|
| Motor drive voltage |
7-12V DC
|
3.5~5.5V DC
|
8.2-45VDC |
2.5V-13.5V
|
Maximum drive current
|
1A each way |
1.5A |
1.6A |
1.2A continuous current (per channel)
2A (continuous pulse)
3.2A (single pulse)
|
Motor drive using pins
|
PIN4/5/6/7 (Arduino Controllor)
|
/ |
D4，D5，D6
D7，D8，D12
|
D3,4,5,6,7,8,11,12
|
Dimension
|
56x57mm
|
63 x 58mm
|
83*55*25mm
|
52mm * 53mm
|
Weight (g)
|
60 |
64 |
48 |
24 |
Frequently used With
|
FIT0565/FIT0520/
FIT0450/FIT0492/
N20 Series
|
FIT0565/FIT0520/
FIT0450/FIT0492/
N20 Series
|
FIT0278/FIT0503
|
FIT0565/FIT0520/
FIT0450/FIT0492/
N20 Series
|
Key Features
|
With motor indicator
|
8-way servo interface
DC motor x4/stepper motor x2(multiplexed with motor interface)
|
Full step, 1/2, 1/4, 1/8, 1/16, 1/32 step mode
|
High-speed drive capability, can drive ordinary 2-phase stepper motor to 5000RPM, and drive quad DC at the same time
|
|
|
Gravity: 2x2A Motor Shield for Arduino Twin
|
TMC260 Stepper Motor Driver Shield
|
2x2A DC Motor Shield for Arduino
|
| SKU |
DFR0502
|
DRI0017
|
DRI0035
|
DRI0009
|
Chip
|
TB6612FNG
|
L298
|
TMC260
|
L298P
|
Operating voltage
|
2.7~5.5V
|
5V |
5V
|
5V |
| Motor drive voltage |
12V (peak value)
|
4.8 ～ 35V
|
40V max
|
6.5~12v(VIN Power Supply),4.8~35V (External Power Source)
|
Maximum drive current
|
1.2A continuous current (per channel)
2A (continuous pulse)
3.2A (single pulse)
|
up to 2A/channel
|
up to 2A per motor coil
|
2A |
Motor drive using pins
|
D4 D5 D6 D7
|
D10,11,12,13
|
/ |
Pin 4,5,6,7 are used to drive two DC motor
|
Dimension
|
68.5mm×53.3mm
|
56x57mm
|
|
55x55mm
|
Weight (g)
|
36 |
35 |
35 |
60 |
Frequently used With
|
FIT0565/FIT0520/
FIT0450/FIT0492/
N20 Series
|
FIT0565/FIT0520/
FIT0450/FIT0492/
N20 Series
|
FIT0278/FIT0503
|
FIT0565/FIT0520/
FIT0450/FIT0492/
N20 Series
|
Key Features
|
Integrated XBee Slot, XBee, WiFi Bee, Bluetooth Bee, I2C.
|
Mirrored version of DRI0009.
Drive pins: 10, 11, 12, 13
Not compatible with IO expansion board V7.1. The control port is four, which reduces the overhead of the Arduino digital ports, and easy to program.
|
Suitable for driving bipolar stepper motors.
SPI serial bus control or STEP/DIR signal control.
Controllers such as Mega with full port expansion.
256 times microstep subdivision.
|
Use mirror motor to drive DRI0017 to aviod the conflicts . Support PWM speed control. Support PLL advance speed control
|
